Wall Mounted Closed Bowl Emergency Eye/Face Wash 45G Hughes False
Artnr: HEWS0045GV / STD-45G
Please share this article with others
Copy this link. After this you can paste and share it.
Productbeschrijving
Plumbed in eye/face wash for indoor use but can, where practical, be located outdoors.
DVGW:
0
Quickly go to
Overzicht
Technische specificaties
- Wall mounted configuration keeps the floor clear and allows installation close to the point of hazard
- Lidded bowl with integral lid protects the bowl and diffusers from dust and debris between activations
- Lid is mechanically linked to the valve so pulling it down automatically starts the water flow for rapid, intuitive operation
- High flow rate aerated diffusers provide effective yet gentle irrigation across the eyes and face
- Flow regulator valve maintains a consistent, comfortable flow within the recommended pressure range
- Suitable for indoor use and, where practical, outdoor use in warm climates
- Designed to meet EN15154 and ANSI Z358.1‑2014
Productbeschrijving
This wall mounted closed bowl eye/face wash is a plumbed‑in emergency unit designed for indoor use and, where practical, outdoor installation in warmer climates. The robust closed ASA bowl incorporates an integral lid that protects the internal bowl and diffusers from dust, dirt and other contaminants, keeping the unit clean and ready for operation between weekly activations. Pulling the lid down automatically opens the operating valve and starts the flow of water in a single, intuitive motion that is easy to use under stress. High flow rate aerated diffusers provide an effective yet gentle washing action across the eyes and face, helping to remove hazardous substances without causing further injury. A flow regulator valve maintains a consistent, comfortable flow within the recommended pressure range. Designed in accordance with EN15154 and ANSI Z358.1‑2014, it offers compliant performance for a wide range of industrial and commercial environments
Technische Specificaties
Algemene specificaties
| Materiaal | Acrylonitrile styrene acrylate (ASA) |
|---|---|
| Materiaal Leidingen | uPVC |
| Activation Method Eye Wash | Pull Lid Down |
| Ambient Temp Max C | 35 |
| Ambient Temp Min C | 5 |
| Constant Water Supply | Ja |
| Berijdbaar | Nee |
| EFW Material | Closed ASA Bowl |
| High Hazard Seismic Zone | Nee |
| High Hazard Seismic Zone | Nee |
| High Hazard Seismic Zone | Nee |
| Materiaal | Acrylonitrile styrene acrylate (ASA) |
| Material Group | Kunststof |
| Operation Duration Min | 15.000000 |
| CGA Fittings | Nee |
Test resultaten
| Werkdruk Min (bar) | 2.000000 |
|---|
Afmetingen
| Afmetingen (cm) | 22.7 x 32 x 36cm |
|---|
